Molasses Tobacco Packing Machine for Overwrapper

INTRODUCTION

The machine is suitable for packing tobacco, molasses,mustard, chili sauce etc.  The integrated processes of bag making, measuring filling, sealing cutting, counting and hot pressing codes can be done automatically. Packing material includes several kinds of heat seal lamination, such as PET/plated AL/PE, PET/PE, PAPER/PE, NYLON etc.

TECHNICAL PARAMETER

1. Working Speed	18 cartons/min
2. PLC	Siemens
3. Text Display	YB43
4. Technical Ducoment	English only
5. Ambient Temp	18-23℃
6. Ambient RH	50-85% RH
7. Compressed Air	From 3-C154 connect to come over
8. Diameter Supply Line	compress air, Inside diameter 8-10mm nylon tube
9. Voltage	380 V, 3 Phase 60 HZ
10. Connected Load:	2.12 KW
11. Safety Loop Voltage	24 V
12.Neutral wire required	yes
13. Year two class preparation	According to user’s needs to order

1.nature: Polypropylene BOPP for heat-sealed, can be stretched in vertical two ways. The specification should conform to the Nation Standard GB/12026-89.

2. dosage 19-23g/ m2

3. width 350mm

4. diameter of bobbin core diameter 75mm

17.Tear strip

1.Nature of Anti-stretch is strong,force of break no less than 10N, plain and straight, without spirals.

2. width 2.5mm

3. diameter of core diameter 28mm

4. dosage 40-70g/ m2

Features:

1. All stainless steel cover meets to GMP standard.

2. equipped with antipollution and dustproof device.

3. Automatic adjustment of pouch size and filling range.

4. Photocell controller is easy to manipulate.

5. Automatic self support lubricating system, the machine can work 24 hours

6. The operation facility is controlled by American Intel computer, all function is displayed with digital screen.

7. Minimum sealing temperature variation employs PID temperature; the tolerance is controlled by ± 2%.

8. Along with assembling automatic no packing alarm system, help user to economize cost.

9. Equipped with easy open system.
