Product Details


Cigarettes/Filter Rod Multifunctional Test Station series




Sample Requirement


Sample circumference range: 21 ~ 28mm
Sample length range: 80 ~ 150mm
Capacity of sample incoming system >=50P

With printing


Cigarettes/Filter Rod Multifunction Test Station series (function includes:Weight, Circumference & diameter, Pressure Drop & Ventilation, Length, Hardness)


Summary:


Using Windows XP Embedded operating system;


Built-in Industrial PC;


Using high-precision sensor;


Automated testing, fast measurement;


Possess the fault diagnosis and self-checking function;


Simultaneous measurement of multiple items;


10.4-inch TFT color LCD screen or 12.1-inch Industrial Panel PC plug-in type, friendly interface, easy to grasp;

Rugged design;


Modular design, each module relative antagonistic;


Data interface:parallel port\serial interface\Ethernet interface\USB\Keyboard and mouse interface;

Low cost of ownership.


Requirements:


POWER Supply:110 volts/60Hz or 220 volts/50Hz. Please state voltage and frequency requirements at time of order.


Compressed air:5 bar, oil free.


MTS    Cigarette/Filter Rod Multifunction Test Station




Specifications


Test Project

Range

Resolution

Accuracy

Weight

0~200g

0.001g

±0.001g

Circumference

21~28mm

0.005mm

±0.01mm

Length

80~150mm

0.005mm

±0.05mm

Draw Resistance

0~8000Pa

10Pa

1.0% F.S.D

Ventilation Ratio

0~100%

0.1%

±1.0%

Hardness

Pressure: 2.94N±0.01N

Pressing time: 15s±1s

Resolution:   0.001mm

±0.5%


1. Sample circumference range:21 ~ 28mm

2. Sample length range:80 ~ 150mm

3. Capacity of sample incoming system:>=50P

4. With printing
